XCMG XE1250 Excavator Spare Parts -11

860202458 Nut
860160620 Buffer Plunger
860202449 Screw M16×105
860160632 Oil Pipe A
801100559 2-225 O-Ring 47.22×3.53
860160628 Piston Rod
860160630 Cylinder Barrel
805142118 Hex Socket Screw
860160629 End Cover
860202453 Steel Wire Retaining Ring
860160609 Dust Seal
860160611 Guide Ring
860160610 Rod Seal Ring
860202497 Buffer Ring
860202498 Sliding Bushing
860202499 Steel Wire Retaining Ring
860202441 O-Ring Backup Ring
803196953 O-Ring 247.02×5.33
860202490 Plug
860160635 Clamp Assembly A
805338278 Washer 10 GB/T97.1-2002
805046615 Bolt M10×50 GB/T5782-2000
860134839 Hex Socket Screw M16×75
860155664 Pressure Plate A
805238371 Nut M10 GB/T6170-2000
805139963 Screw M16×190 GB/T70.1-2008
860160634 Oil Passage Block B
805140237 Screw M14×180 GB/T70.1-2008
803420928 O-Ring
860160633 Oil Passage Block A
860156157 Screw Plug
860203520 O-Ring
860200797 Spring
860202461 Valve Spool
860159562 Dipper Cylinder Repair Kit
318005609 Hose Clamp
318005610 Pressure Plate
329900983 Reinforced Flat Washer
805050706 Bolt M14×130 GB/T5782-2000
318005612 Hose Clamp
318005613 Pressure Plate
329900983 Reinforced Flat Washer
805050706 Bolt M14×130 GB/T5782-2000
860160621 Piston Rod
860160622 End Cover
860160623 Cylinder Barrel
860202426 Buffer Sleeve
860160624 Piston
860202273 Washer
860160598 Nut
860202423 Steel Wire Retaining Ring
860160603 Dust Seal
860155691 Open Retaining Ring
860155690 Rod Seal Ring
860155692 Buffer Ring
860155693 Sliding Bushing
860155694 Hole Steel Wire Retaining Ring
860160613 Retaining Ring
860155695 O-Ring
805141810 Hex Socket Screw
860160615 Dirt Ring
860160614 Guide Ring
860160612 Hole Seal Ring
860160601 O-Ring Backup Ring
803198144 O-Ring 117.07×3.53
860150880 Screw M12×20
860160625 Oil Passage Block
860200758 O-Ring
805139894 Screw M14×120 GB/T70.1-2008
860160600 Flange Dust Cover Plate
860160626 Oil Passage Block
801100559 2-225 O-Ring 47.22×3.53
805140542 Screw M16×150 GB/T70.1-2008
860155702 Flange Dust Cover Plate
860202490 Plug
860160597 Spherical Plain Bearing
860160627 Pressure Cover
805140813 Screw M6×30 GB/T70.1-2008
860155678 Dust Seal
860160604 Graphite Copper Bushing
860174197 Self-Lubricating Bearing
860159561 Boom Cylinder Repair Kit
318005615 Pipe Clamp
329900983 Reinforced Flat Washer
805046659 Bolt M14×100 GB/T5782-2000
318005590 Bracket
318005580 Pipe Clamp Assembly
318005591 Pipe Clamp Assembly
329900304 Reinforced Flat Washer
805006280 Bolt M16×45 GB/T5783-2000
318005581 Pipe Clamp
329900303 Reinforced Flat Washer
805046650 Bolt M12×100 GB/T5782-2000
318005592 Pipe Clamp
329900303 Reinforced Flat Washer
805046648 Bolt M12×90 GB/T5782-2000
318005607 Pipe Clamp
329900983 Reinforced Flat Washer
805046659 Bolt M14×100 GB/T5782-2000
318007111 Muffler System
318007112 Radiator System
318007114 Fuel System
318005763 Engine Mounting
318007113 Air Filter System
800161364 Muffler Exhaust Tail Pipe
805046640 Bolt M12×60 GB/T5782-2000
318007134 Copper Washer
805238372 Nut M12 GB/T6170-2000
800157455 Muffler Assembly
318005710 U-Bolt
805046525 Bolt M10×20 GB/T5783-2000
329900297 Reinforced Large Washer
318005713 Clamp
805011330 Bolt M10×25 GB/T5783-2000
318007130 Bracket
800105351 Rubber Sleeve Clamp
800161366 Air Pipe
318007126 Steel Pipe Assembly
800158158 Air Pipe
800163868 Clamp
318008066 Muffler Bracket
329900303 Reinforced Flat Washer
329900302 Reinforced Flat Washer
805006287 Bolt M12×40 GB/T5783-2000
329900298 Reinforced Large Washer
805006412 Bolt M12×30 GB/T5783-2000
800141072 Clamp
800158156 Exhaust Hose
318007133 Copper Washer
318005706 Bracket Assembly
318008005 Bracket Assembly
318005707 Bracket Assembly
318005705 Bracket Assembly
318005883 Bent Plate
318008006 Exhaust Connection Pipe
800158157 V-Clamp
805006414 Bolt M12×45 GB/T5783-2000
318005712 Bent Plate
318007116 Exhaust Connection Pipe
318007132 Copper Washer
804015924 Radiator Assembly
318005724 Tie Rod
318005730 Wind Deflector
318005731 Sponge
329900295 Reinforced Large Washer
805046591 Bolt M20×50 GB/T5783-2000
805046508 Bolt M8×20 GB/T5783-2000
318005739 Tie Rod
318007058 Wind Deflector
318007059 Sponge
318005733 Spacer Block
329900942 Bolt
318005727 Bent Plate
318005732 Sponge
800177082 Clamp
800158163 Water Pipe
800177088 Clamp
800161359 Water Pipe
329900296 Reinforced Large Washer
803697901 Rubber-Lined Hose Clamp
800177090 Clamp
800158161 Water Pipe
800163883 Clamp
805046509 Bolt M8×25 GB/T5783-2000
803697891 Rubber-Lined Hose Clamp
329900301 Reinforced Flat Washer
800158162 Water Pipe
800158160 Water Pipe
800163896 Clamp
800163894 Clamp
800173219 Air Pipe
318009269 Steel Pipe
800164314 Air Pipe
318005737 Bent Plate
329900298 Reinforced Large Washer
805238372 Nut M12 GB/T6170-2000
318007063 Sponge
318008110 Steel Pipe Assembly
318006872 Bracket
805006412 Bolt M12×30 GB/T5783-2000
329900303 Reinforced Flat Washer
329900884 U-Shaped Pipe Clamp
318007060 Sponge
318007055 Wind Deflector
318007057 Sponge
318007374 Adjusting Shim
318007375 Adjusting Shim
318006875 Bracket
318005717 Bracket Assembly
318007532 Adjusting Shim
318007533 Adjusting Shim
318007924 Bent Plate
318007062 Sponge
329900302 Reinforced Flat Washer
805046525 Bolt M10×20 GB/T5783-2000
318007056 Wind Deflector
800158162 Water Pipe
800161362 Water Pipe
800173220 Air Pipe
318009317 Washer
318009318 Washer
800177080 Clamp
803173220 Joint Body
800161369 Water Pipe
800161360 Diesel Pipe Assembly
800161365 Diesel Pipe Assembly
800161358 Diesel Pipe Assembly
803697900 Rubber-Lined Hose Clamp
329900301 Reinforced Flat Washer
805046504 Bolt M8×16 GB/T5783-2000
800161363 Diesel Pipe Assembly
803173684 Joint
803697899 Rubber-Lined Hose Clamp
800161656 Hose Clamp
800154806 Fuel-Water Separator
805139977 Screw M8×35 GB/T70.1-2008
800160630 Rubber Sleeve Clamp
800161367 Diesel Pipe Assembly
803309096 Joint
801141485 Ball Valve
318007109 Joint
805139976 Screw M8×30 GB/T70.1-2008
800159013 Joint
804402341 O-Ring
329900968 Bolt
318010200 Washer
318005765 Engine Front Support Leg
800152860 Protective Cover
800152859 Engine Support Shock Absorber
318005768 Washer
805239826 Nut M36 GB/T6184-2000
805006391 Bolt M16×90 GB/T5782-2000
318005773 Spacer Sleeve
805338377 Washer 18 GB/T1230-2006
805047251 Bolt M18×50 GB/T5783-2000
318005771 Connection Plate
329900303 Reinforced Flat Washer
805006413 Bolt M12×35 GB/T5783-2000
800360472 Transfer Case
318005764 Engine Rear Support Leg
329900925 Bolt
318005772 Spacer Sleeve
800345930 Coupling Assembly
800157290 Drain Valve M27×2.0
805300038 Washer 27 JB/T982-1977
318007613 Drain Port Joint Block
805011330 Bolt M10×25 GB/T5783-2000
318007098 Joint
801141485 Ball Valve
803309096 Joint
800173260 Paper Gasket
800180539 Oil Hose
318010525 Drain Joint
803424475 O-Ring (FKM) 24.99×3.53
805046525 Bolt M10×20 GB/T5783-2000
318007363 Oil Filling Pipe
329900302 Reinforced Flat Washer
800140935 Engine Assembly
803697900 Rubber-Lined Hose Clamp
805046508 Bolt M8×20 GB/T5783-2000
329900930 Bolt
805338298 Washer 22 GB/T1230-2006
800,800141086 Engine Shock Absorber Cover
800104646 Engine Shock Absorber
318001248 Washer
805238491 Nut M22 GB/T6184-2000
329900301 Reinforced Flat Washer
805046452 Bolt M10×55 GB/T5782-2000
318005775 Lubrication Block
